Model No.: Flange
Standard: ASTM, MAKAN, GB, bs
Sama Ada Aloi: Bukan aloi
Bertolak Ansur: ± 1%
Perkhidmatan Pemprosesan: Kimpalan, Menyahtapis, Menumbuk
Nama produk: Blind Flanges
Size: 1/2” to 60”, DN 12mm to DN 1500mm
Pressure Class: Class 150 to Class 2,500, PN 2.5 to PN 250
Facing: RF / RTJ
Tolerance: ±1%
Cabon Steel: A105, A350 LF2
Stainless Steel: A182 F304/F304L/F316/F316L/F321
Alloy Steel: F11, F12
Pembungkusan: Standard Export Packaging
Pembungkusan: Pembungkusan marin standard, atau seperti yang dikehendaki oleh pelanggan
Produktiviti: 10000 Tons Per Month
Pengangkutan: Ocean,Land,Express
Tempat asal: China
Sokongan mengenai: 10000 Tons Per Month
Kod HS: 3917400000
Port: Qingdao,Shanghai,Tianjin
Jenis bayaran: T/T,D/P,Money Gram,L/C
Incoterm: FOB,CFR,CIF,EXW
Bebibir ini digunakan sebagai titik penamatan kepada sistem paip. Buta buta mempunyai permukaan kosong dengan titik bolt agar sesuai dengan paip.
Flange JPI Class 150 BL RF A20 B3 Paip bebibir dan kelengkapan
Flange buta digunakan untuk menutup hujung sistem paip. Ia adalah sejenis plat bulat tanpa memegang pusat tetapi dengan semua lubang bolt yang betul. Flange buta ini boleh didapati dalam pelbagai saiz dan bahan dan digunakan untuk memberikan lebih dekat di hujung paip, injap atau muncung peralatan. Flange ini membantu dalam akses mudah ke garisan sebaik sahaja ia dimeteraikan. Flange buta kadang -kadang dibuat khas atau dimesin untuk menerima paip bersaiz nominal yang mana pengurangan sedang dibuat. Paip dikimpal paip keluli SMLS sejuk
Beban buta biasanya digunakan dalam petrokimia, kejuruteraan paip, perkhidmatan awam & kerja air.
Bebibir paip buta sering digunakan untuk aplikasi tekanan tinggi.
Pengurangan ini boleh menjadi pengurangan berulir atau pengurangan dikimpal. Paip keluli galvanized
Saiz: 1/2 "hingga 60", DN 12mm hingga DN 1500mm
Kelas Tekanan: Kelas 150 hingga Kelas 2,500, PN 2.5 hingga PN 250
Menghadapi: RF / RTJ
Bahan:
Keluli Cabon: A105, A350 LF2
Keluli tahan karat: A182 F304/F304L/F316/F316L/F321
Alloy Steel: F11, F12
|
Product Name |
Blind Flanges |
|
Material |
Cabon steel: A105, A350 LF2 Stainless steel: A182 F304/F304L/F316/F316L/F321 Alloy steel: F11, F12 |
|
Size |
1/2” to 60”, DN 12mm to DN 1500mm |
|
Pressure Class |
Class 150 to Class 2,500, PN 2.5 to PN 250 |
|
Applications |
Blind Flanges are commonly used in petrochemical, pipe engineering, public services & water works. Blind pipe flanges are often used for high pressure applications. |
|
Delivery Time |
Usually within 7-10 days after receipt of advance payment |
|
Payment Terms |
T/T 30% Down Payment,Balance Will be Paid Before Shippment |
|
Advantage of Blind Flanges |
A much more cost efficient way to seal a pipe when doing repairs Blind flanges are convenient to install They can save a good amount of time and money |
| Nominal Pipe Size | Outside Diameter of Flange | Diameter of Raised Face | Thickness of Flanges Min. | Diameter of Bolt Circle | Diameter of Bolt Holes | Number of Bolts | Approximate Weight kgs |
| NPS | O | R | tf | W | I | n | |
| 1/2 | 90 | 34.9 | 9.6 | 60.3 | 15.9 | 4 | 0.44 |
| 3/4 | 100 | 42.9 | 11.2 | 69.9 | 15.9 | 4 | 0.64 |
| 1 | 110 | 50.8 | 12.7 | 79.4 | 15.9 | 4 | 0.90 |
| 1 1/4 | 115 | 63.5 | 14.3 | 88.9 | 15.9 | 4 | 1.13 |
| 1 1/2 | 125 | 73.0 | 15.9 | 98.4 | 15.9 | 4 | 1.50 |
| 2 | 150 | 92.1 | 17.5 | 120.7 | 19.1 | 4 | 2.38 |
| 2 1/2 | 180 | 104.8 | 20.7 | 139.7 | 19.1 | 4 | 4.09 |
| 3 | 190 | 127.0 | 22.3 | 152.4 | 19.1 | 4 | 4.97 |
| 3 1/2 | 215 | 139.7 | 22.3 | 177.8 | 19.1 | 8 | 6.20 |
| 4 | 230 | 157.2 | 22.3 | 190.5 | 19.1 | 8 | 7.18 |
| 5 | 255 | 185.7 | 22.3 | 215.9 | 22.2 | 8 | 8.83 |
| 6 | 280 | 215.9 | 23.9 | 241.3 | 22.2 | 8 | 11.55 |
| 8 | 345 | 269.9 | 27.0 | 298.5 | 22.2 | 8 | 20.07 |
| 10 | 405 | 323.8 | 28.6 | 362.0 | 25.4 | 12 | 28.87 |
| 12 | 485 | 381.0 | 30.2 | 431.8 | 25.4 | 12 | 44.18 |
| 14 | 535 | 412.8 | 33.4 | 476.3 | 28.6 | 12 | 59.07 |
| 16 | 595 | 469.9 | 35.0 | 539.8 | 28.6 | 16 | 76.36 |
| 18 | 635 | 533.4 | 38.1 | 577.9 | 31.8 | 16 | 94.51 |
| 20 | 700 | 584.2 | 41.3 | 635.0 | 31.8 | 20 | 123.94 |
| 24 | 815 | 692.2 | 46.1 | 749.3 | 34.9 | 20 | 187.90 |
| Norminal Pipe Size | O.D.of Flange, O | Min.Thick-ness of BL Flange, tf | Raised Fase Diam., R | Diam of Bolt Circle | No.of Bolt Holes | Diam.of Bolt Hole | Approxi-mate Weight kgs |
| 26 | 890 | 111.3 | 727 | 806.4 | 28 | 44.5 | 528.79 |
| 28 | 950 | 115.9 | 784 | 863.6 | 28 | 47.6 | 626.51 |
| 30 | 1020 | 127.0 | 841 | 927.1 | 28 | 50.8 | 789.17 |
| 32 | 1085 | 134.9 | 895 | 984.2 | 28 | 54.0 | 946.54 |
| 34 | 1160 | 144.2 | 953 | 1054.1 | 24 | 60.3 | 1158.72 |
| 36 | 1215 | 150.9 | 1010 | 1104.9 | 28 | 60.3 | 1323.63 |
Kategori produk : Keluli struktur > Bebibir paip dan kelengkapan
